Envisivent Removable Magnetic Mud-In Flush Mounted Wall Air Return Vent

Envisivent  |  SKU: 08CB5060  |  Barcode: 628903145859
$9400 CAD
Shipping calculated at checkout.
Size

Members earn 188 CSR Points when they buy this item. Sign up or log in.

Couldn't load pickup availability

Add sophistication to your home with the Envisivent Removable Air Return Vent. The vent is designed to replace the standard cover for a 14" x 8" or 30" x 8" duct. Also available in 8" x 8", 10" x 10", 12" x 12", 14" x 8", and 14" x 14". Featuring directionally vented air slots and a seamless finish that blends into interior walls to give your home or office space a contemporary aesthetic.

8” x 8” Removable Magnetic Mud-In Flush Mounted Air Return Vent

  • angled horizontal slots
  • Over 13 square inches (84 square cm) of open vent area
  • 4 magnetic tabs on Vent Cover for easy removal
  • Moisture, mold, and water resistant
  • Primed and ready to paint
  • Eco-friendly manufacturing and non-hazardous
  • Frame Material: Satin Coat Galvanized Steel
  • Vent Cover Material: Triple Fibre Reinforced Cement Board

Product Specifications

General Overall Dimensions: 10.125" x 10.125" x 0.5"
Vented Opening Dimensions: 5.613" x 5.613"
Vent Cover Dimensions: 7.625" x 7.625"
Frame Material: Satin Coat Galvanized Steel
Vent Cover Material: Triple Fibre Reinforced Cement Board

Specification Sheet |   MSDS Sheet

10” x 10” Removable Magnetic Mud-In Flush Mounted Air Return Vent

  • 11 angled horizontal slots
  • Over 26.9 square inches (173.5 square cm) of open vent area
  • 4 magnetic tabs on Vent Cover for easy removal
  • Moisture, mold, and water resistant
  • Primed and ready to paint
  • Eco-friendly manufacturing and non-hazardous
  • Frame Material: Satin Coat Galvanized Steel
  • Vent Cover Material: Triple Fibre Reinforced Cement Board

Product Specifications

General Overall Dimensions:  12.125" x 12.125" x 0.5"
Vented Opening Dimensions:  7.645" x 7.645"
Vent Cover Dimensions:  9.629" x 9.629"
Frame Material: Satin Coat Galvanized Steel
Vent Cover Material: Triple Fibre Reinforced Cement Board

Specification Sheet |  MSDS Sheet

12” x 12” Removable Magnetic Mud-In Flush Mounted Air Return Vent

  • 14 angled horizontal slots
  • Over 43.6 square inches (281.2 square cm) of open vent area
  • 4 magnetic tabs on Vent Cover for easy removal
  • Moisture, mold, and water resistant
  • Primed and ready to paint
  • Eco-friendly manufacturing and non-hazardous
  • Frame Material: Satin Coat Galvanized Steel
  • Vent Cover Material: Triple Fibre Reinforced Cement Board

Product Specifications

General Overall Dimensions:  14.313" x 14.313" x 0.5"
Vented Opening Dimensions:  9.75" x 9.75"
Vent Cover Dimensions:  11.857" x 11.857"
Frame Material: Satin Coat Galvanized Steel
Vent Cover Material: Triple Fibre Reinforced Cement Board

Specification Sheet |  MSDS Sheet

14" x 8" Removable Magnetic Mud-In Flush Mounted Air Return Vent

  • 18 straight horizontal slots
  • Over 32 square inches (206 square cm) of open vent area
  • Moisture, mold, and water resistant
  • Machine-beveled outer edges for seamless finishing
  • Primed and ready to paint
  • Eco-friendly manufacturing and non-hazardous
  • Vent Cover Material: Triple Fibre Reinforced Cement Board
  • Designed to be installed with 0.5″ thick drywall

Specification Sheet|MSDS Sheet

14" x 10" Removable Magnetic Mud-In Flush Mounted Air Return Vent

  • 26 angled horizontal slots
  • Over 47 square inches (303 square cm) of open vent area
  • 4 magnetic tabs on the vent cover for easy removal
  • Moisture, mold, and water resistant
  • Primed and ready to paint
  • Eco-friendly manufacturing and non-hazardous
  • Frame Material: Satin Coat Galvanized Steel
  • Vent Cover Material: Triple Fibre Reinforced Cement Board
  • Designed to be installed with 0.5" thick drywall

Product Specifications

General Overall Dimensions: 16” x 13-¾” x ½” (406mm x 350mm x 12mm)
Vented Opening Dimensions: 11-¾” x 8-¾” (298mm x 222mm)
Vent Cover Dimensions: 13-⅜” x 11” (330mm x 280mm)
Frame Material: Satin Coat Galvanized Steel
Vent Cover Material: Triple Fibre Reinforced Cement Board

Specification Sheet | MSDS Sheet

14" x 14" Removable Magnetic Mud-In Flush Mounted Air Return Vent

  • 30 angled horizontal slots
  • Over 53 square inches (342 square cm) of open vent area
  • 4 magnetic tabs on Vent Cover for easy removal
  • Moisture, mold, and water resistant
  • Primed and ready to paint
  • Eco-friendly manufacturing and non-hazardous
  • Frame Material: Satin Coat Galvanized Steel
  • Vent Cover Material: Triple Fibre Reinforced Cement Board

Product Specifications

General Overall Dimensions:  16.375" x 16.375" x 0.5"
Vented Opening Dimensions:  11.875" x 11.875"
Vent Cover Dimensions:  13.75" x 13.75"
Frame Material: Satin Coat Galvanized Steel
Vent Cover Material: Triple Fibre Reinforced Cement Board

Specification Sheet | MSDS Sheet

24" X 8" Removable Magnetic Mud-In Flush Mounted Air Return Vent

  • 33 angled horizontal slots
  • Over 77.8 square inches (502 square cm) of open vent area
  • Moisture, mold, and water resistant
  • Machine beveled outer edges for seamless finishing
  • Primed and ready to paint
  • Eco-friendly manufacturing and non-hazardous
  • Vent Cover Material: Triple Fibre Reinforced Cement Board

Product Specifications

General Overall Dimensions:  28.5" x 12.5" x 0.5"
Vented Opening Dimensions:  26.25" x 10.25"
Vent Cover Dimensions:  26" x 10"
Frame Material: Satin Coat Galvanized Steel
Vent Cover Material: Triple Fibre Reinforced Cement Board

Specification Sheet | MSDS Sheet

30" X 8" Removable Magnetic Mud-In Flush Mounted Air Return Vent

  • 48 directionally vented air slots
  • Over 90 square inches (580 square cm) of open vent area
  • 4 magnetic tabs on Vent Cover for easy removal
  • Moisture, mold, and water resistant
  • Primed and ready to paint
  • Eco-friendly manufacturing and non-hazardous

Product Specifications

General Overall Dimensions:  32” x 12-¼” x ½" (813mm x 311mmx 12mm)
Vented Opening Dimensions:  27-¾”  x 8” (704mm x 203mm)
Vent Cover Dimensions:  29-⅜” x 11” (737mm x 229mm)
Frame Material: Satin Coat Galvanized Steel
Vent Cover Material: Triple Fibre Reinforced Cement Board

Specification Sheet | MSDS Sheet

NOTE: SIZES LARGER THAN 14" x 8" ARE NOT SUITABLE FOR CEILING INSTALLATION WITHOUT THE USE OF CEILING CLIPS WHICH CAN BE ORDERED HERE
